Sunway 12v 200Ahr Gel Battery datasheet

Deep Cycle 12V 200Ah GEL Solar Battery AGM Storage Battery



Products  Specification

Model
6-GFM-200Ah
6-GFM(G)-200Ah
Cells Per Unit
6
Voltage Per Unit
12
Capacity
200Ah@10hr-rate to 1.80V per cell @25°C
Weight
57.9kg
62.4kg
Internal Resistance
Approx. 3 mΩ
Approx. 3.5 mΩ
Terminal
F8
Max.Discharge Current
3000A (5 sec)
Design Life
6~8 years
10~15 years
Maximum Charging Current
50A
Reference Capacity
C10 200.0AH
C3 153.3AH
C1 110.4AH
C10 200.0AH
C3 144.7AH
C1 110.1AH
Float Charging Voltage
13.6 V~13.8 V @ 25°C
Temperature Compensation: -20mV/°C/Cell
Cycle Use Voltage
14.4 V~14.9 V @ 25°C
Temperature Compensation: -30mV/°C/Cell
Operating Temperature Range
Discharge: -15°C~50°C
Charge: 0°C~40°C
Storage: -15°C~40°C
Discharge: -20°C~60°C
Charge: 0°C~50°C
Storage: -20°C~60°C
Normal Operating Temperature Range
25°C±5°C
Self Discharge
Less than 3% at 25°C per month
Container Material
A.B.S. UL94-HB, UL94-V0 Optional
